pyadi-jif: JESD204 tools for mere mortals
summary
Open-source configuration library pyadi-jiff models clock chips, converters and FPGA constraints, solves mixed-integer PLL/divider equations with CPLEX or Gekko, and emits device-tree and FPGA constraints via pyadi-iio. Demonstrated on ADI hardware (AD9680/AD9144 with a 9523 clock) by changing sample rate from 1 GS/s to 500 MS/s: lane rate becomes 5 Gbps, core clock 125 MHz, device-tree updated, JESD link comes up and GNU Radio shows the expected 40 MHz tone — the workflow works end-to-end.
AI-written summary · about
chapters (7)
- 0:00pyadi-jif and JESD204 intro
- 8:44JESD204 config challenges
- 14:27JIFF and pyadi-jif tools
- 17:55JIFF clock and config fixes
- 20:46JIFF to hardware translation
- 24:58Live demo: GNU Radio & hardware
- 28:08Summary & pyadi-jif resources
