World's first live soldering stream of a #LoRaWAN device
summary
Claims a world's first live soldering stream building a double-sided four‑layer #LoRaWAN node end to end over eight hours, using stencil + solder paste, reflow oven, hot air and basic bench tools. It places ~80 SMDs including STM32WL, TCXO, secure element and a buck‑boost regulator; measures 1.8 microamps sleep on earlier boards; hits build problems with the regulator and multiple reflows, bypasses the regulator, and ultimately transmits packets with RSSI −55, mostly functional.
AI-written summary · about
chapters (28)
- 0:00Start
- 5:25Types of Soldering Methods To Do the Smd Soldering
- 7:11Generic Node Prototype
- 11:04Generic Node
- 11:57Soldering Process
- 31:40Capacitors
- 34:59Temperature and Humidity Sensor
- 42:23Esd Diode
- 1:37:32Apply the Solder
- 1:40:48Clean Up the Stencil
- 1:56:30Power Supply
- 2:03:39Bulk Capacitors
- 2:34:16Diodes
- 2:38:06Reset Button
- 2:38:45Resettable Fuse
- 2:56:26Matching Network Tuning
- 3:03:53100k Resistors
- 3:18:48Small Analog Switch
- 3:42:12Preheating the Oven
- 4:06:12Cleaning Up the Board
- 4:09:55Power Up Test
- 4:24:03Basic Test
- 4:38:42Hot Air Reflow
- 5:08:54Soldering the Buck Boost Converter
- 5:38:59Bypass the Black Boost Converter
- 5:51:18Low Power
- 5:52:58Hacked Version of the Generic Node
- 6:00:19Lorawan Application
